BPO - Beam Profile Optimized

Information
Special and flexible designs for optimized beam profiles according to customers' needs such as:
  • low M2
  • special flatness
  • single longitudinal mode
  1. Lamp pumped BPO
  2. Hybrid BPO
  3. Options
  Repetition Rate Pulse Energy
(1064 nm)
Pulse Energy
(532 nm)
Pulse Energy
(355 nm)
Pulse Energy
(266 nm)
Stability RMS
(1064 nm)
SpitLight 600 - 10 BPO 10 Hz > 700 mJ > 420 mJ > 180 mJ > 90 mJ < 0.7 %
SpitLight 1000-10 BPO 10 Hz > 1000 mJ > 600 mJ > 320 mJ > 100 mJ < 0.7 %
SpitLight 2000 - 10 BPO 10 Hz > 2000 mJ > 1200 mJ > 540 mJ > 130 mJ < 1.0 %
  Repetition Rate Pulse Energy
(1064 nm)
Pulse Energy
(532 nm)
Pulse Energy
(355 nm)
Pulse Energy
(266 nm)
Stability RMS
(1064 nm)

SLM Hybrid 10 10 Hz > 500 mJ > 300 mJ > 170 mJ > 80 mJ < 0.7 %
SLM Hybrid 20 20 Hz > 450 mJ  > 280 mJ > 150 mJ > 70 mJ < 0.8 %
SLM Hybrid 30 30 Hz > 400 mJ  > 250 mJ > 125 mJ  > 60 mJ < 0.9 %

Various laser models are availabe in a beam profile optimized version:

  • from 400 mJ
  • please call for more info: +49 899 360 1400
  • e-mail info(at)innolas-laser.com
